Avago Technologies US, Inc. HDSP-N100
- Mfg. Part Number
- HDSP-N100
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- Display Modules - LED Character and Numeric
- Brief Description
- DISPLAY 7SEG ALGAAS CA
- Datasheet Download
- HDSP-N100.pdf
Availability of HDSP-N100
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HDSP-N100, we specialize in Avago Technologies US, Inc. all series electronic components. HDSP-N100 can be shipped within 24 hours after order. If you have any demands for HDSP-N100, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HDSP-N100 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HDSP-N100
| Internal Part Number | EIS-HDSP-N100 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 1/Mar/2010 | |
| Standard Package | 120 | |
| Category | Optoelectronics | |
| Family | Display Modules - LED Character and Numeric | |
| Series | - | |
| Number of Characters | 1 | |
| Size / Dimension | 1.090" H x 0.786" W x 0.330" D (27.69mm x 19.96mm x 8.38mm) | |
| Digit/Alpha Size | 0.80" (20.32mm) | |
| Display Type | 7-Segment | |
| Common Pin | Common Anode | |
| Color | Red | |
| Voltage - Forward (Vf) (Typ) | 1.7V | |
| Current - Test | 5mA | |
| Millicandela Rating | 3.5mcd | |
| Wavelength - Peak | 645nm | |
| Power Dissipation (Max) | 37mW | |
| Package / Case | 18-DIP (0.600", 15.24mm), 12 Leads | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HDSP-N100 | |
| Related Links | HDSP, HDSP-N100 Datasheet, Avago Technologies US, Inc. Distributor | |
