NKK Switches ISC15ANP4
- Mfg. Part Number
- ISC15ANP4
- Manufacturer
- NKK Switches
- Product Category
- Programmable Display Switches
- Brief Description
- SWITCH OLED 64RGB X 48 12V
- Datasheet Download
- ISC15ANP4.pdf
Availability of ISC15ANP4
Available Quantity
6135 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 64.53160
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISC15ANP4, we specialize in NKK Switches all series electronic components. ISC15ANP4 can be shipped within 24 hours after order. If you have any demands for ISC15ANP4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISC15ANP4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISC15ANP4
| Internal Part Number | EIS-ISC15ANP4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | OLED SmartSwitch/Display Appl Notes | |
| Product Training Modules | Switch Basics Smart Switch Overview 3D CAD Models How to Program a SmartSwitch Development Kit | |
| Video File | OLED Pushbutton in Action NKK SmartSwitch™ - Another Geek Moment | DigiKey | |
| RoHS Information | AT, IS Series, Cert of Compliance | |
| Featured Product | SmartSwitch™ Pushbuttons OLED SmartSwitch™ & SmartDisplay™ | |
| 3D Model | ISC15ANP4 | |
| PCN Design/Specification | IS Series OLED Life Increase 29/Jun/2010 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Programmable Display Switches | |
| Series | SmartSwitch™ | |
| Packaging | Bulk | |
| Type | Pushbutton, OLED | |
| Style | - | |
| Display Mode | 65536 Colors, Passive Matrix | |
| LED Color | - | |
| Viewing Area | 15.5mm L x 11.6mm W | |
| Face Size | 23.13mm L x 20.59mm W | |
| Pixel Format | 64 x 48 | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.1A @ 12VDC | |
| Supply Voltage | 2.4 ~ 3.5VDC | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Operating Temperature | -20°C ~ 70°C | |
| Operating Force | 2.0 Newtons | |
| LED Forward Current | - | |
| LED Forward Voltage | - | |
| Travel Range | 4.5mm | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISC15ANP4 | |
| Related Links | ISC1, ISC15ANP4 Datasheet, NKK Switches Distributor | |
