Souriau Connection Technology JBXEA1J06MCSDS
- Mfg. Part Number
- JBXEA1J06MCSDS
- Manufacturer
- Souriau Connection Technology
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 6POS PNL MNT PIN CRIMP
- Datasheet Download
- JBXEA1J06MCSDS.pdf
Availability of JBXEA1J06MCSDS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 30.27200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JBXEA1J06MCSDS, we specialize in Souriau Connection Technology all series electronic components. JBXEA1J06MCSDS can be shipped within 24 hours after order. If you have any demands for JBXEA1J06MCSDS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JBXEA1J06MCSDS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JBXEA1J06MCSDS
| Internal Part Number | EIS-JBXEA1J06MCSDS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | JBX | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Male Pins | |
| Number of Positions | 6 | |
| Shell Size - Insert | 1 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Bulkhead - Front or Rear Side Nut | |
| Termination | Crimp | |
| Fastening Type | Push-Pull | |
| Orientation | J | |
| Ingress Protection | IP40 | |
| Shell Material, Finish | Brass, Chrome over Nickel | |
| Contact Finish | Gold | |
| Features | Shielded | |
| Contact Finish Thickness | 19.7µin (0.50µm) | |
| Current Rating | 7A | |
| Voltage - Rated | 660VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JBXEA1J06MCSDS | |
| Related Links | JBXEA1J, JBXEA1J06MCSDS Datasheet, Souriau Connection Technology Distributor | |
