C&K Components MC07L3NZGD
- Mfg. Part Number
- MC07L3NZGD
- Manufacturer
- C&K Components
- Product Category
- Rotary Switches
- Brief Description
- SWITCH ROTARY
- Datasheet Download
- MC07L3NZGD.pdf
Availability of MC07L3NZGD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.55460
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC07L3NZGD, we specialize in C&K Components all series electronic components. MC07L3NZGD can be shipped within 24 hours after order. If you have any demands for MC07L3NZGD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC07L3NZGD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC07L3NZGD
| Internal Part Number | EIS-MC07L3NZGD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rotary Switches | |
| Series | M | |
| Number of Positions | 7 | |
| Index Stops | Fixed | |
| Number of Decks | 1 | |
| Number of Poles per Deck | 1 | |
| Circuit per Deck | SP7T | |
| Contact Timing | Non-Shorting (BBM) | |
| Current Rating | 250mA (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Round (3.17mm Dia) | |
| Actuator Length | 10.16mm | |
| Angle of Throw | 30° | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Features | - | |
| Depth Behind Panel | 14.86mm | |
| Panel Cutout Dimensions | Circular - 6.60mm Dia | |
| Operating Force, Torque | 4 ~ 7 in-oz | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC07L3NZGD | |
| Related Links | MC07L, MC07L3NZGD Datasheet, C&K Components Distributor | |
MC07L3NZGD Details Description
