NXP Semiconductors/Freescale Semiconductor, Inc. MCIMX6D5EYM10AC
- Mfg. Part Number
- MCIMX6D5EYM10AC
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Embedded - Microprocessors
- Brief Description
- IC MPU I.MX6D 1.0GHZ 624FCBGA
- Datasheet Download
- MCIMX6D5EYM10AC.pdf
Availability of MCIMX6D5EYM10AC
Available Quantity
5320 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 36.57000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MCIMX6D5EYM10AC, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. MCIMX6D5EYM10AC can be shipped within 24 hours after order. If you have any demands for MCIMX6D5EYM10AC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MCIMX6D5EYM10AC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MCIMX6D5EYM10AC
| Internal Part Number | EIS-MCIMX6D5EYM10AC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | i.MX 6 Series Applications Processors Introduction | |
| PCN Design/Specification | I.MX 6DUAL6QUAD Update 04/Jun/2013 I.MX 6Dual/6Quad Errata Update 11/Dec/2013 I.MX6DQ Rev 1.3 Errata Revision 28/Jan/2014 I.MX6 Datasheet Update 01/May/2014 Reference Manual Update 01/Aug/2014 Design Change 01/Aug/2014 Errata Update 01/Jul/2015 Datasheet Correction 16/Nov/2015 | |
| PCN Assembly/Origin | i.MX6Q/D Assembly Site 24/Jan/2014 Assembly Site Addition 05/Mar/2015 Reference Manual Update 28/Jul/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 300 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microprocessors | |
| Series | i.MX6D | |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-A9 | |
| Number of Cores/Bus Width | 2 Core, 32-Bit | |
| Speed | 1.0GHz | |
| Co-Processors/DSP | Multimedia; NEON™ SIMD | |
| RAM Controllers | LPDDR2, LVDDR3, DDR3 | |
| Graphics Acceleration | Yes | |
| Display & Interface Controllers | Keypad, LCD | |
| Ethernet | 10/100/1000 Mbps (1) | |
| SATA | SATA 3Gbps (1) | |
| USB | USB 2.0 + PHY (4) | |
| Voltage - I/O | 1.8V, 2.5V, 2.8V, 3.3V | |
| Operating Temperature | -20°C ~ 105°C | |
| Security Features | ARM TZ, Boot Security, Cryptography, RTIC, Secure Fusebox, Secure JTAG, Secure Memory, Secure RTC, Tamper Detection | |
| Package / Case | 624-FBGA, FCBGA | |
| Supplier Device Package | 624-FCBGA (21x21) | |
| Additional Interfaces | CAN, I²C, I²S, MMC/SD/SDIO, SAI, SPI, SSI, UART | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MCIMX6D5EYM10AC | |
| Related Links | MCIMX6D, MCIMX6D5EYM10AC Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
MCIMX6D5EYM10AC Details Description
