Bourns Inc. RL622-222K-RC
- Mfg. Part Number
- RL622-222K-RC
- Manufacturer
- Bourns Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.2MH 80MA 6.8 OHM TH
- Datasheet Download
- RL622-222K-RC.pdf
Availability of RL622-222K-RC
Available Quantity
6811 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29925
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RL622-222K-RC, we specialize in Bourns Inc. all series electronic components. RL622-222K-RC can be shipped within 24 hours after order. If you have any demands for RL622-222K-RC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RL622-222K-RC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RL622-222K-RC
| Internal Part Number | EIS-RL622-222K-RC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Magnetic Product Overview | |
| PCN Assembly/Origin | Magnetic products Oct/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | RL622 | |
| Packaging | Bulk | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 2.2mH | |
| Tolerance | ±10% | |
| Current Rating | 80mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 6.8 Ohm Max | |
| Q @ Freq | 20 @ 252kHz | |
| Frequency - Self Resonant | 900kHz | |
| Operating Temperature | -55°C ~ 105°C | |
| Frequency - Test | 252kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.335" Dia (8.50mm) | |
| Height - Seated (Max) | 0.433" (11.00mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RL622-222K-RC | |
| Related Links | RL622-, RL622-222K-RC Datasheet, Bourns Inc. Distributor | |
