Molex Connector Corporation 0026481043
- Mfg. Part Number
- 0026481043
- Manufacturer
- Molex Connector Corporation
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN BKWY HEADER 4POS STR TIN
- Datasheet Download
- 0026481043.pdf
Availability of 0026481043
Available Quantity
19002 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.34570
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0026481043, we specialize in Molex Connector Corporation all series electronic components. 0026481043 can be shipped within 24 hours after order. If you have any demands for 0026481043, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0026481043 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0026481043
| Internal Part Number | EIS-0026481043 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Tin Whisker Formation Change 27/Jul/2011 | |
| Product Training Modules | KK Low Power and Signal Interconnect Family | |
| RoHS Information | 0026481043 Cert of Compliance | |
| Featured Product | KK® Interconnect Solutions | |
| 3D Model | 26-48-1043.stp | |
| PCN Design/Specification | Copper/Nickel Plating 01/Aug/2011 Reflow Matte Tin Plating 27/Jul/2011 | |
| PCN Other | KK 396 Cosmetic Deviation 07/Jul/2014 | |
| Standard Package | 14,400 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | KK® 41681 | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded, Breakaway | |
| Number of Positions | 4 | |
| Number of Positions Loaded | All | |
| Pitch | 0.156" (3.96mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | 0.450" (11.43mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Tin | |
| Contact Finish Thickness | 60µin (1.52µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0026481043 | |
| Related Links | 00264, 0026481043 Datasheet, Molex Connector Corporation Distributor | |
0026481043 Details Description
