Molex Connector Corporation 0026482112
- Mfg. Part Number
- 0026482112
- Manufacturer
- Molex Connector Corporation
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER 11POS .156 R/A GOLD
- Datasheet Download
- 0026482112.pdf
Availability of 0026482112
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.39191
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0026482112, we specialize in Molex Connector Corporation all series electronic components. 0026482112 can be shipped within 24 hours after order. If you have any demands for 0026482112, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0026482112 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0026482112
| Internal Part Number | EIS-0026482112 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 26-48-2112 Cert of Compliance | |
| Featured Product | KK® Interconnect Solutions | |
| PCN Design/Specification | Gold Plating Removal 01/Aug/2011 | |
| PCN Other | KK 396 Cosmetic Deviation 07/Jul/2014 | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | KK® 41662 | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded, Breakaway | |
| Number of Positions | 11 | |
| Number of Positions Loaded | All | |
| Pitch | 0.156" (3.96mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | 0.573" (14.55mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 20µin (0.51µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0026482112 | |
| Related Links | 00264, 0026482112 Datasheet, Molex Connector Corporation Distributor | |
0026482112 Details Description
