Molex Connector Corporation 0038007089
- Mfg. Part Number
- 0038007089
- Manufacturer
- Molex Connector Corporation
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- KK200 POL WFR ASY 2599M03A02
- Datasheet Download
- 0038007089.pdf
Availability of 0038007089
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.34075
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0038007089, we specialize in Molex Connector Corporation all series electronic components. 0038007089 can be shipped within 24 hours after order. If you have any demands for 0038007089, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0038007089 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0038007089
| Internal Part Number | EIS-0038007089 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 38007089 Cert of Compliance | |
| Standard Package | 5,000 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | KK® 2599 | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded | |
| Number of Positions | 3 | |
| Number of Positions Loaded | 2 | |
| Pitch | 0.200" (5.08mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | 0.450" (11.43mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | Position 2 Not Loaded | |
| Contact Finish | Tin | |
| Contact Finish Thickness | 100µin (2.54µm) | |
| Color | Natural | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0038007089 | |
| Related Links | 00380, 0038007089 Datasheet, Molex Connector Corporation Distributor | |
