Molex Connector Corporation 0039532115
- Mfg. Part Number
- 0039532115
- Manufacturer
- Molex Connector Corporation
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FFC VERT 11POS 1.25MM PCB
- Datasheet Download
- 0039532115.pdf
Availability of 0039532115
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.52171
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0039532115, we specialize in Molex Connector Corporation all series electronic components. 0039532115 can be shipped within 24 hours after order. If you have any demands for 0039532115, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0039532115 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0039532115
| Internal Part Number | EIS-0039532115 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 39532115 Cert of Compliance | |
| 3D Model | 39-53-2115.stp | |
| PCN Design/Specification | 5571,5597 Series Molding Resin 09/Dec/2014 | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | 5597 | |
| Packaging | Tray | |
| Flat Flex Type | FFC, FPC | |
| Mounting Type | Through Hole | |
| Connector/Contact Type | Contacts, Vertical, 1 Sided | |
| Number of Positions | 11 | |
| Pitch | 0.049" (1.25mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.30mm | |
| Height Above Board | 0.295" (7.50mm) | |
| Locking Feature | Slide Lock | |
| Cable End Type | Straight | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Tin Bismuth | |
| Housing Material | Polybutylene Terephthalate (PBT), Polyester | |
| Actuator Material | Polybutylene Terephthalate (PBT), Polyester | |
| Features | Zero Insertion Force (ZIF) | |
| Voltage Rating | 200V | |
| Operating Temperature | -20°C ~ 80°C | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 1A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0039532115 | |
| Related Links | 00395, 0039532115 Datasheet, Molex Connector Corporation Distributor | |
0039532115 Details Description
