Littelfuse 0230007.DRT1P
- Mfg. Part Number
- 0230007.DRT1P
- Manufacturer
- Littelfuse
- Product Category
- Fuses
- Brief Description
- FUSE GLASS 7A 125VAC/VDC 2AG
- Datasheet Download
- 0230007.DRT1P.pdf
Availability of 0230007.DRT1P
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.49840
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0230007.DRT1P, we specialize in Littelfuse all series electronic components. 0230007.DRT1P can be shipped within 24 hours after order. If you have any demands for 0230007.DRT1P, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0230007.DRT1P Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0230007.DRT1P
| Internal Part Number | EIS-0230007.DRT1P | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,500 | |
| Category | Circuit Protection | |
| Family | Fuses | |
| Series | 230 | |
| Packaging | Tape & Reel (TR) | |
| Fuse Type | Cartridge, Glass | |
| Current Rating | 7A | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 125V | |
| Response Time | Slow | |
| Package / Case | Cartridge, Non-Standard (Axial) | |
| Mounting Type | Through Hole | |
| Breaking Capacity @ Rated Voltage | 400A | |
| Melting I²t | 464 | |
| Approvals | CE, CSA, PSE, UL | |
| Operating Temperature | -55°C ~ 125°C | |
| Color | - | |
| Size / Dimension | 0.177" Dia x 0.571" L (4.50mm x 14.50mm) | |
| DC Cold Resistance | 0.0116 Ohm | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0230007.DRT1P | |
| Related Links | 023000, 0230007.DRT1P Datasheet, Littelfuse Distributor | |
0230007.DRT1P Details Description
