Littelfuse 0315005.H
- Mfg. Part Number
- 0315005.H
- Manufacturer
- Littelfuse
- Product Category
- Fuses
- Brief Description
- FUSE GLASS 5A 250VAC 3AB 3AG
- Datasheet Download
- 0315005.H.pdf
Availability of 0315005.H
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0315005.H, we specialize in Littelfuse all series electronic components. 0315005.H can be shipped within 24 hours after order. If you have any demands for 0315005.H, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0315005.H Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0315005.H
| Internal Part Number | EIS-0315005.H | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Fuseology - Introduction to Fuses | |
| Standard Package | 100 | |
| Category | Circuit Protection | |
| Family | Fuses | |
| Series | 315 | |
| Packaging | Bulk | |
| Fuse Type | Cartridge, Glass | |
| Current Rating | 5A | |
| Voltage Rating - AC | 250V | |
| Voltage Rating - DC | - | |
| Response Time | Slow | |
| Package / Case | 3AB, 3AG, 1/4" x 1-1/4" (Axial) | |
| Mounting Type | Through Hole | |
| Breaking Capacity @ Rated Voltage | 200A | |
| Melting I²t | 140 | |
| Approvals | CSA, METI, UL | |
| Operating Temperature | -55°C ~ 125°C | |
| Color | - | |
| Size / Dimension | 0.275" Dia x 1.275" L (6.99mm x 32.39mm) | |
| DC Cold Resistance | 0.0212 Ohm | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0315005.H | |
| Related Links | 0315, 0315005.H Datasheet, Littelfuse Distributor | |
