Mill-Max 0670-0-15-01-30-02-10-0
- Mfg. Part Number
- 0670-0-15-01-30-02-10-0
- Manufacturer
- Mill-Max
- Product Category
- Terminals - PC Pin Receptacles, Socket Connectors
- Brief Description
- CONN RECEPT PIN .015-.025" .135"
- Datasheet Download
- 0670-0-15-01-30-02-10-0.pdf
Availability of 0670-0-15-01-30-02-10-0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.06131
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0670-0-15-01-30-02-10-0, we specialize in Mill-Max all series electronic components. 0670-0-15-01-30-02-10-0 can be shipped within 24 hours after order. If you have any demands for 0670-0-15-01-30-02-10-0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0670-0-15-01-30-02-10-0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0670-0-15-01-30-02-10-0
| Internal Part Number | EIS-0670-0-15-01-30-02-10-0 | |
| Lead Free Status / RoHS Status | ||
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - PC Pin Receptacles, Socket Connectors | |
| Series | 0670 | |
| Packaging | Bulk | |
| Tail Type | No Tail | |
| Termination | Solder | |
| Length - Overall | 0.135" (3.43mm) | |
| Accepts Pin Diameter | 0.015" ~ 0.025" (0.38mm ~ 0.64mm) | |
| Mounting Hole Diameter | 0.060" (1.52mm) | |
| Pin Hole Diameter | 0.043" (1.09mm) | |
| Flange Diameter | 0.072" (1.83mm) | |
| Tail Diameter | - | |
| Socket Depth | 0.113" (2.87mm) | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Tin-Lead | |
| Contact Finish Thickness | 100µin (2.54µm) | |
| Features | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Board Thickness | - | |
| Insertion Force | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0670-0-15-01-30-02-10-0 | |
| Related Links | 0670-0-15-0, 0670-0-15-01-30-02-10-0 Datasheet, Mill-Max Distributor | |
