Molex Connector Corporation 0761551627
- Mfg. Part Number
- 0761551627
- Manufacturer
- Molex Connector Corporation
- Product Category
- Backplane Connectors - Specialized
- Brief Description
- IMPACT BP 4X16 DUAL WALL SN
- Datasheet Download
- 0761551627.pdf
Availability of 0761551627
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.92500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0761551627, we specialize in Molex Connector Corporation all series electronic components. 0761551627 can be shipped within 24 hours after order. If you have any demands for 0761551627, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0761551627 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0761551627
| Internal Part Number | EIS-0761551627 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Backplane Roadmap | |
| RoHS Information | 761551627 Cert of Compliance | |
| 3D Model | 76155-1627.stp0761551627 .pdf | |
| Standard Package | 224 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Specialized | |
| Series | Impact™ 76155 | |
| Packaging | Tray | |
| Connector Usage | - | |
| Connector Type | Header, Male Pins | |
| Connector Style | Impact™ | |
| Number of Positions | 192 | |
| Number of Positions Loaded | All | |
| Pitch | 0.053" (1.35mm) | |
| Number of Rows | 12 | |
| Number of Columns | 16 | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit | |
| Contact Layout, Typical | 64 Differential Pairs | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Color | Black | |
| Current Rating | - | |
| Material Flammability Rating | UL94 V-0 | |
| Operating Temperature | -55°C ~ 85°C | |
| Voltage Rating | 30V | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0761551627 | |
| Related Links | 07615, 0761551627 Datasheet, Molex Connector Corporation Distributor | |
