TE Connectivity AMP Connectors 1-1740533-7
- Mfg. Part Number
- 1-1740533-7
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular Connectors - Free Hanging, Panel Mount
- Brief Description
- CONN DUOPLUG POW
- Datasheet Download
- 1-1740533-7.pdf
Availability of 1-1740533-7
Available Quantity
8767 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.44988
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1-1740533-7, we specialize in TE Connectivity AMP Connectors all series electronic components. 1-1740533-7 can be shipped within 24 hours after order. If you have any demands for 1-1740533-7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1-1740533-7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1-1740533-7
| Internal Part Number | EIS-1-1740533-7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 1-1740533-7.pdf | |
| Standard Package | 1,078 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Free Hanging, Panel Mount | |
| Series | DuoPlug | |
| Packaging | Bulk | |
| Connector Type | Receptacle | |
| Contact Type | Female Blade Socket | |
| Number of Positions | 7 | |
| Pitch | 0.197" (5.00mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Mounting Type | Free Hanging (In-Line), Right Angle | |
| Fastening Type | Locking Ramp | |
| Cable Termination | IDC | |
| Wire Type | Discrete | |
| Wire Gauge | - | |
| Features | Mates to PCB | |
| Contact Finish | Tin | |
| Contact Finish Thickness | - | |
| Color | Natural | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1-1740533-7 | |
| Related Links | 1-174, 1-1740533-7 Datasheet, TE Connectivity AMP Connectors Distributor | |
1-1740533-7 Details Description
