TE Connectivity AMP Connectors 1-5767003-1
- Mfg. Part Number
- 1-5767003-1
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN PLUG 114POS VERT .025 SMD
- Datasheet Download
- 1-5767003-1.pdf
Availability of 1-5767003-1
Available Quantity
5040 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 35.93200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1-5767003-1, we specialize in TE Connectivity AMP Connectors all series electronic components. 1-5767003-1 can be shipped within 24 hours after order. If you have any demands for 1-5767003-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1-5767003-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1-5767003-1
| Internal Part Number | EIS-1-5767003-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 1-5767003-1 Statement of ComplianceRoHS 2 Statement | |
| Featured Product | Centerline Matched Impedance Connectors | |
| 3D Model | 1-5767003-1.pdf | |
| PCN Obsolescence/ EOL | Multiple Devices 24/Aug/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | MICTOR | |
| Packaging | Tube | |
| Connector Type | Plug, Outer Shroud Contacts | |
| Number of Positions | 114 | |
| Pitch | 0.025" (0.64mm) | |
| Number of Rows | 2 | |
| Mounting Type | Surface Mount | |
| Features | Board Guide, Ground Bus (Plane) | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Mated Stacking Heights | 11mm, 20mm | |
| Height Above Board | 0.419" (10.64mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1-5767003-1 | |
| Related Links | 1-576, 1-5767003-1 Datasheet, TE Connectivity AMP Connectors Distributor | |
