TE Connectivity AMP Connectors 1-84534-5
- Mfg. Part Number
- 1-84534-5
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FFC VERT 15POS 1.25MM PCB
- Datasheet Download
- 1-84534-5.pdf
Availability of 1-84534-5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.20735
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1-84534-5, we specialize in TE Connectivity AMP Connectors all series electronic components. 1-84534-5 can be shipped within 24 hours after order. If you have any demands for 1-84534-5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1-84534-5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1-84534-5
| Internal Part Number | EIS-1-84534-5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 1-84534-5 Statement of ComplianceRoHS 2 Statement | |
| Featured Product | TE Connectivity - FPC Connectors | |
| 3D Model | 1-84534-5.pdf | |
| Standard Package | 21,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | - | |
| Packaging | Bulk | |
| Flat Flex Type | FFC | |
| Mounting Type | Through Hole | |
| Connector/Contact Type | Contacts, Vertical, 1 Sided | |
| Number of Positions | 15 | |
| Pitch | 0.049" (1.25mm) | |
| Termination | Kinked Pin | |
| FFC, FCB Thickness | 0.30mm | |
| Height Above Board | 0.307" (7.80mm) | |
| Locking Feature | - | |
| Cable End Type | Tapered | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Tin | |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | |
| Actuator Material | - | |
| Features | - | |
| Voltage Rating | 50V | |
| Operating Temperature | -40°C ~ 85°C | |
| Material Flammability Rating | - | |
| Current Rating | 1A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1-84534-5 | |
| Related Links | 1-84, 1-84534-5 Datasheet, TE Connectivity AMP Connectors Distributor | |
1-84534-5 Details Description
