ST 1.5KE7V5CARL
- Mfg. Part Number
- 1.5KE7V5CARL
- Manufacturer
- ST
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 6.4VWM 14.5VC DO201
- Datasheet Download
- 1.5KE7V5CARL.pdf
Availability of 1.5KE7V5CARL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1.5KE7V5CARL, we specialize in ST all series electronic components. 1.5KE7V5CARL can be shipped within 24 hours after order. If you have any demands for 1.5KE7V5CARL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1.5KE7V5CARL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1.5KE7V5CARL
| Internal Part Number | EIS-1.5KE7V5CARL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | 1.5KE View All Specifications | |
| Standard Package | 1,900 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | 1.5KE, TRANSIL™ | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 1 | |
| Voltage - Reverse Standoff (Typ) | 6.4V | |
| Voltage - Breakdown (Min) | 7.13V | |
| Voltage - Clamping (Max) @ Ipp | 14.5V | |
| Current - Peak Pulse (10/1000µs) | 690A (8/20µs) | |
| Power - Peak Pulse | 1500W (1.5kW) | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | 4250pF @ 1MHz | |
| Operating Temperature | - | |
| Mounting Type | Through Hole | |
| Package / Case | DO-201AA, DO-27, Axial | |
| Supplier Device Package | DO-201 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1.5KE7V5CARL | |
| Related Links | 1.5KE7, 1.5KE7V5CARL Datasheet, ST Distributor | |
1.5KE7V5CARL Details Description
