Littelfuse 1.5SMC30A
- Mfg. Part Number
- 1.5SMC30A
- Manufacturer
- Littelfuse
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 25.6VWM 41.4VC SMD
- Datasheet Download
- 1.5SMC30A.pdf
Availability of 1.5SMC30A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.24795
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1.5SMC30A, we specialize in Littelfuse all series electronic components. 1.5SMC30A can be shipped within 24 hours after order. If you have any demands for 1.5SMC30A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1.5SMC30A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1.5SMC30A
| Internal Part Number | EIS-1.5SMC30A | |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Transient Voltage Suppression (TVS) Diodes | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | 1.5SMC | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 25.6V | |
| Voltage - Breakdown (Min) | 28.5V | |
| Voltage - Clamping (Max) @ Ipp | 41.4V | |
| Current - Peak Pulse (10/1000µs) | 36.7A | |
| Power - Peak Pulse | 1500W (1.5kW) | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AB, SMC | |
| Supplier Device Package | DO-214AB (SMCJ) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1.5SMC30A | |
| Related Links | 1.5S, 1.5SMC30A Datasheet, Littelfuse Distributor | |
