E-Switch 1003P2T6B11M1QE
- Mfg. Part Number
- 1003P2T6B11M1QE
- Manufacturer
- E-Switch
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE 3PDT 5A 120V
- Datasheet Download
- 1003P2T6B11M1QE.pdf
Availability of 1003P2T6B11M1QE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.06975
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1003P2T6B11M1QE, we specialize in E-Switch all series electronic components. 1003P2T6B11M1QE can be shipped within 24 hours after order. If you have any demands for 1003P2T6B11M1QE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1003P2T6B11M1QE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1003P2T6B11M1QE
| Internal Part Number | EIS-1003P2T6B11M1QE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 100 Series RoHS Cert of Compliance | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 100 | |
| Packaging | Bulk | |
| Circuit | 3PDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Flat Anti-Rotation | |
| Actuator Length | 12.30mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 40,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1003P2T6B11M1QE | |
| Related Links | 1003P2T, 1003P2T6B11M1QE Datasheet, E-Switch Distributor | |
