TE Connectivity AMP Connectors 103672-5
- Mfg. Part Number
- 103672-5
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER RTANG 6POS PCB TIN
- Datasheet Download
- 103672-5.pdf
Availability of 103672-5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.69992
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 103672-5, we specialize in TE Connectivity AMP Connectors all series electronic components. 103672-5 can be shipped within 24 hours after order. If you have any demands for 103672-5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 103672-5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
103672-5
| Internal Part Number | EIS-103672-5 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 103672-5.pdf | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 30 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | AMPMODU MTE | |
| Packaging | Tube | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 6 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | 0.230" (5.84mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Fastening Type | Latch Holder | |
| Features | Board Lock | |
| Contact Finish | Tin-Lead | |
| Contact Finish Thickness | 100µin (2.54µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 103672-5 | |
| Related Links | 1036, 103672-5 Datasheet, TE Connectivity AMP Connectors Distributor | |
103672-5 Details Description
