Bourns Inc. 1120-3R9M
- Mfg. Part Number
- 1120-3R9M
- Manufacturer
- Bourns Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 3.9UH 11.4A 5 MOHM TH
- Datasheet Download
- 1120-3R9M.pdf
Availability of 1120-3R9M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1120-3R9M, we specialize in Bourns Inc. all series electronic components. 1120-3R9M can be shipped within 24 hours after order. If you have any demands for 1120-3R9M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1120-3R9M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1120-3R9M
| Internal Part Number | EIS-1120-3R9M | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 88 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | 1120 | |
| Packaging | Bulk | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 3.9µH | |
| Tolerance | ±20% | |
| Current Rating | 11.4A | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 5 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 105°C | |
| Frequency - Test | 1kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.810" Dia (20.57mm) | |
| Height - Seated (Max) | 0.840" (21.34mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1120-3R9M | |
| Related Links | 1120, 1120-3R9M Datasheet, Bourns Inc. Distributor | |
1120-3R9M Details Description
