C&K Components 1203M2S3V3BE2
- Mfg. Part Number
- 1203M2S3V3BE2
- Manufacturer
- C&K Components
- Product Category
- Slide Switches
- Brief Description
- SWITCH SLIDE DPDT 0.4VA 20V
- Datasheet Download
- 1203M2S3V3BE2.pdf
Availability of 1203M2S3V3BE2
Available Quantity
5188 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.61808
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1203M2S3V3BE2, we specialize in C&K Components all series electronic components. 1203M2S3V3BE2 can be shipped within 24 hours after order. If you have any demands for 1203M2S3V3BE2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1203M2S3V3BE2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1203M2S3V3BE2
| Internal Part Number | EIS-1203M2S3V3BE2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Introduction to Electromechanical Switches | |
| PCN Assembly/Origin | Series Transfer 26/Nov/2012 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Slide Switches | |
| Series | 1000 | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Contact Timing | Not Specified | |
| Switch Function | On-Off-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 20V | |
| Voltage Rating - DC | 20V | |
| Actuator Type | Standard | |
| Actuator Length | 4.72mm | |
| Contact Material | Copper | |
| Contact Finish | Gold | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Features | Black Actuator, Epoxy Sealed Terminals | |
| Actuator Material | Polyamide (PA), Nylon | |
| Switch Travel | 2.16mm | |
| Operating Temperature | -30°C ~ 65°C | |
| Mechanical Life | - | |
| Electrical Life | 100,000 Cycles | |
| Operating Force | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1203M2S3V3BE2 | |
| Related Links | 1203M2, 1203M2S3V3BE2 Datasheet, C&K Components Distributor | |
