API Delevan 1330R-30G
- Mfg. Part Number
- 1330R-30G
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.7UH 355MA 550 MOHM
- Datasheet Download
- 1330R-30G.pdf
Availability of 1330R-30G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.76650
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1330R-30G, we specialize in API Delevan all series electronic components. 1330R-30G can be shipped within 24 hours after order. If you have any demands for 1330R-30G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1330R-30G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1330R-30G
| Internal Part Number | EIS-1330R-30G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | 1330R | |
| Packaging | Tape & Reel (TR) | |
| Type | - | |
| Material - Core | Iron | |
| Inductance | 2.7µH | |
| Tolerance | ±2% | |
| Current Rating | 355mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 550 mOhm Max | |
| Q @ Freq | 37 @ 7.9MHz | |
| Frequency - Self Resonant | 100MHz | |
| Operating Temperature | -55°C ~ 105°C | |
| Frequency - Test | 7.9MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 2-SMD | |
| Size / Dimension | 0.313" L x 0.115" W (7.95mm x 2.92mm) | |
| Height - Seated (Max) | 0.145" (3.68mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1330R-30G | |
| Related Links | 1330, 1330R-30G Datasheet, API Delevan Distributor | |
1330R-30G Details Description
