Honeywell Sensing and Productivity Solutions 14CE101-10
- Mfg. Part Number
- 14CE101-10
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Snap Action, Limit Switches
- Brief Description
- EXPLOSION-PROOF LIMIT SWES
- Datasheet Download
- 14CE101-10.pdf
Availability of 14CE101-10
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 254.11000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 14CE101-10, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. 14CE101-10 can be shipped within 24 hours after order. If you have any demands for 14CE101-10, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 14CE101-10 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
14CE101-10
| Internal Part Number | EIS-14CE101-10 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | 14CE100 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC) | |
| Voltage Rating - AC | 240V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round (Pin Plunger) | |
| Mounting Type | Chassis Mount | |
| Termination Style | Cable Leads | |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | |
| Features | Cable Length 10m, Explosion Proof | |
| Operating Force, Torque | 1200gf | |
| Release Force | 450gf | |
| Pretravel | 0.071" (1.8mm) | |
| Differential Travel | 0.004" (0.1mm) | |
| Overtravel | 0.118" (3.0mm) | |
| Operating Position | 0.618" (15.7mm) | |
| Mechanical Life | 10,000,000 Cycles | |
| Electrical Life | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 14CE101-10 | |
| Related Links | 14CE1, 14CE101-10 Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
14CE101-10 Details Description
