TE Connectivity AMP Connectors 1747047-1
- Mfg. Part Number
- 1747047-1
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular Connectors - Housings
- Brief Description
- GRACE INERTIA CONNECTOR 6.5 3POS
- Datasheet Download
- 1747047-1.pdf
Availability of 1747047-1
Available Quantity
5664 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.19074
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1747047-1, we specialize in TE Connectivity AMP Connectors all series electronic components. 1747047-1 can be shipped within 24 hours after order. If you have any demands for 1747047-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1747047-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1747047-1
| Internal Part Number | EIS-1747047-1 | |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 1747047-1.pdf | |
| PCN Design/Specification | 174704(7,9) Color 16/Dec/2014 | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Housings | |
| Series | Grace Inertia, GIC | |
| Packaging | Bulk | |
| Connector Type | Plug | |
| Contact Type | Tab | |
| Number of Positions | 3 | |
| Pitch | 0.256" (6.50mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Contact Termination | Crimp | |
| Fastening Type | Latch Lock | |
| Color | Blue | |
| Features | - | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1747047-1 | |
| Related Links | 1747, 1747047-1 Datasheet, TE Connectivity AMP Connectors Distributor | |
1747047-1 Details Description
