Weidmüller 1761962001
- Mfg. Part Number
- 1761962001
- Manufacturer
- Weidmüller
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- TERM BLOCK HDR 21POS R/A 3.5MM
- Datasheet Download
- 1761962001.pdf
Availability of 1761962001
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1761962001, we specialize in Weidmüller all series electronic components. 1761962001 can be shipped within 24 hours after order. If you have any demands for 1761962001, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1761962001 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1761962001
| Internal Part Number | EIS-1761962001 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | Omnimate SL | |
| Packaging | Bulk | |
| Type | Header, Male Pins, Shrouded (2 Side) | |
| Number of Positions | 21 | |
| Positions Per Level | 21 | |
| Number of Levels | 1 | |
| Pitch | 0.138" (3.50mm) | |
| Header Orientation | 90°, Right Angle | |
| Plug Wire Entry | - | |
| Termination Style | Solder | |
| Mounting Type | Through Hole | |
| Current - IEC | 13A | |
| Voltage - IEC | 250V | |
| Current - UL | 10A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | - | |
| Wire Gauge or Range - mm² | - | |
| Color | Black | |
| Operating Temperature | -20°C ~ 100°C | |
| Contact Mating Finish | Tin | |
| Features | Side Stacking | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1761962001 | |
| Related Links | 17619, 1761962001 Datasheet, Weidmüller Distributor | |
