Weidmüller 1769200000
- Mfg. Part Number
- 1769200000
- Manufacturer
- Weidmüller
- Product Category
- Terminal Blocks - Wire to Board
- Brief Description
- TERM BLOCK PCB 5.08MM 28POS BK
- Datasheet Download
- 1769200000.pdf
Availability of 1769200000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 17.06400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1769200000, we specialize in Weidmüller all series electronic components. 1769200000 can be shipped within 24 hours after order. If you have any demands for 1769200000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1769200000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1769200000
| Internal Part Number | EIS-1769200000 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Wire to Board | |
| Series | Omnimate LM | |
| Packaging | Bulk | |
| Number of Levels | 2 | |
| Positions Per Level | 14 | |
| Pitch | 0.200" (5.08mm) | |
| Mating Orientation | Horizontal with Board | |
| Current | 10A | |
| Voltage | 300V | |
| Wire Gauge | 12-24 AWG | |
| Mounting Type | Through Hole | |
| Wire Termination | Screw - Clamping Yoke, Tension Sleeve | |
| Features | Interlocking (Side) | |
| Color | Black | |
| Operating Temperature | -20°C ~ 100°C | |
| Housing Material | Polyamide (PA66), Nylon 6/6 | |
| Contact Material - Plating | Brass - Tin Plated | |
| Clamp Material - Plating | - | |
| Screw Material - Plating | - | |
| Torque - Screw | 0.4-0.5 Nm (3.5-4.4 Lb-In) | |
| Screw Thread | M2.5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1769200000 | |
| Related Links | 17692, 1769200000 Datasheet, Weidmüller Distributor | |
1769200000 Details Description
