Diodes Incorporated 1N5256B-T
- Mfg. Part Number
- 1N5256B-T
- Manufacturer
- Diodes Incorporated
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 30V 500MW DO35
- Datasheet Download
- 1N5256B-T.pdf
Availability of 1N5256B-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1N5256B-T, we specialize in Diodes Incorporated all series electronic components. 1N5256B-T can be shipped within 24 hours after order. If you have any demands for 1N5256B-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1N5256B-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1N5256B-T
| Internal Part Number | EIS-1N5256B-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Cert of Compliance | |
| PCN Obsolescence/ EOL | Select Discrete Devices 20/Feb/2014 | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 30V | |
| Tolerance | ±5% | |
| Power - Max | 500mW | |
| Impedance (Max) (Zzt) | 49 Ohm | |
| Current - Reverse Leakage @ Vr | 100nA @ 23V | |
| Voltage - Forward (Vf) (Max) @ If | 1.1V @ 200mA | |
| Operating Temperature | -65°C ~ 200°C | |
| Mounting Type | Through Hole | |
| Package / Case | DO-204AH, DO-35, Axial | |
| Supplier Device Package | DO-35 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1N5256B-T | |
| Related Links | 1N52, 1N5256B-T Datasheet, Diodes Incorporated Distributor | |
1N5256B-T Details Description
