ON Semiconductor 1SMB43AT3G
- Mfg. Part Number
- 1SMB43AT3G
- Manufacturer
- ON Semiconductor
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 43VWM 69.4VC SMB
- Datasheet Download
- 1SMB43AT3G.pdf
Availability of 1SMB43AT3G
Available Quantity
15171 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.11845
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1SMB43AT3G, we specialize in ON Semiconductor all series electronic components. 1SMB43AT3G can be shipped within 24 hours after order. If you have any demands for 1SMB43AT3G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1SMB43AT3G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1SMB43AT3G
| Internal Part Number | EIS-1SMB43AT3G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | SMB Schottky and Ultrafast Rectifiers 17/Sep/2013 | |
| Standard Package | 1 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 43V | |
| Voltage - Breakdown (Min) | 47.8V | |
| Voltage - Clamping (Max) @ Ipp | 69.4V | |
| Current - Peak Pulse (10/1000µs) | - | |
| Power - Peak Pulse | 600W | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | 400pF @ 1MHz | |
| Operating Temperature | -65°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AA, SMB | |
| Supplier Device Package | SMB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1SMB43AT3G | |
| Related Links | 1SMB4, 1SMB43AT3G Datasheet, ON Semiconductor Distributor | |
1SMB43AT3G Details Description
