TE Connectivity Potter & Brumfield Relays 2-1393810-7
- Mfg. Part Number
- 2-1393810-7
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Product Category
- Signal Relays, Up to 2 Amps
- Brief Description
- RELAY GEN PURPOSE DPDT 2A 24V
- Datasheet Download
- 2-1393810-7.pdf
Availability of 2-1393810-7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 90.15500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2-1393810-7, we specialize in TE Connectivity Potter & Brumfield Relays all series electronic components. 2-1393810-7 can be shipped within 24 hours after order. If you have any demands for 2-1393810-7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2-1393810-7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2-1393810-7
| Internal Part Number | EIS-2-1393810-7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 60 | |
| Category | Relays | |
| Family | Signal Relays, Up to 2 Amps | |
| Series | V23154, AXICOM | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 27mA | |
| Coil Voltage | 24VDC | |
| Contact Form | DPDT (2 Form C) | |
| Contact Rating (Current) | 2A | |
| Switching Voltage | 125VAC, 150VDC - Max | |
| Turn On Voltage (Max) | 11 VDC | |
| Turn Off Voltage (Min) | - | |
| Operate Time | 7.5ms | |
| Release Time | 3ms | |
| Features | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver (Ag), Gold (Au) | |
| Coil Power | 647 mW | |
| Coil Resistance | 890 Ohms | |
| Operating Temperature | -40°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2-1393810-7 | |
| Related Links | 2-139, 2-1393810-7 Datasheet, TE Connectivity Potter & Brumfield Relays Distributor | |
2-1393810-7 Details Description
