Aries Electronics, Inc. 20-005-100T
- Mfg. Part Number
- 20-005-100T
- Manufacturer
- Aries Electronics, Inc.
- Product Category
- Rectangular Cable Assemblies
- Brief Description
- DIP CABLE 20POS
- Datasheet Download
- 20-005-100T.pdf
Availability of 20-005-100T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 18.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 20-005-100T, we specialize in Aries Electronics, Inc. all series electronic components. 20-005-100T can be shipped within 24 hours after order. If you have any demands for 20-005-100T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 20-005-100T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
20-005-100T
| Internal Part Number | EIS-20-005-100T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Cable Assemblies | |
| Family | Rectangular Cable Assemblies | |
| Series | 100 | |
| Connector Type | DIP to DIP | |
| Number of Positions | 20 | |
| Number of Rows | 2 | |
| Pitch - Connector | 0.100" (2.54mm) | |
| Pitch - Cable | 0.050" (1.27mm) | |
| Length | 0.417' (127.00mm, 5.00") | |
| Features | - | |
| Color | Multiple, Ribbon | |
| Shielding | Unshielded | |
| Usage | - | |
| Cable Termination | Solder | |
| Contact Finish | Tin | |
| Contact Finish Thickness | 200µin (5.08µm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 20-005-100T | |
| Related Links | 20-00, 20-005-100T Datasheet, Aries Electronics, Inc. Distributor | |
