FFF 20020130-H021A01LF
- Mfg. Part Number
- 20020130-H021A01LF
- Manufacturer
- FFF
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- TERM BLOCK HDR 2POS 45DEG 5.08MM
- Datasheet Download
- 20020130-H021A01LF.pdf
Availability of 20020130-H021A01LF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.18576
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 20020130-H021A01LF, we specialize in FFF all series electronic components. 20020130-H021A01LF can be shipped within 24 hours after order. If you have any demands for 20020130-H021A01LF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 20020130-H021A01LF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
20020130-H021A01LF
| Internal Part Number | EIS-20020130-H021A01LF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Signal and Power Terminal Blocks | |
| PCN Design/Specification | Multiple Series Improvement 16/Feb/2012 Multiple Devices Design 28/Apr/2014 | |
| PCN Part Number | Anytek Integration 02/Apr/2015 | |
| Standard Package | 400 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | 30-508 | |
| Packaging | Bulk | |
| Type | Header, Male Pins, Shrouded (4 Side) | |
| Number of Positions | 2 | |
| Positions Per Level | 2 | |
| Number of Levels | 1 | |
| Pitch | 0.200" (5.08mm) | |
| Header Orientation | 45° | |
| Plug Wire Entry | - | |
| Termination Style | Solder | |
| Mounting Type | Through Hole | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 15A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | - | |
| Wire Gauge or Range - mm² | - | |
| Color | Green | |
| Operating Temperature | -40°C ~ 115°C | |
| Contact Mating Finish | Tin | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 20020130-H021A01LF | |
| Related Links | 20020130-, 20020130-H021A01LF Datasheet, FFF Distributor | |
20020130-H021A01LF Details Description
