Vishay Semiconductor/Diodes Division 20CTQ045STRL
- Mfg. Part Number
- 20CTQ045STRL
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 45V D2PAK
- Datasheet Download
- 20CTQ045STRL.pdf
Availability of 20CTQ045STRL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 20CTQ045STRL, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. 20CTQ045STRL can be shipped within 24 hours after order. If you have any demands for 20CTQ045STRL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 20CTQ045STRL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
20CTQ045STRL
| Internal Part Number | EIS-20CTQ045STRL | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Video File | Functions & Parameters of the “Simplest” Semiconductor | |
| Standard Package | 800 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Configuration | 1 Pair Common Cathode | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 45V | |
| Current - Average Rectified (Io) (per Diode) | 10A | |
| Voltage - Forward (Vf) (Max) @ If | 640mV @ 10A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 2mA @ 45V | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | D2PAK | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 20CTQ045STRL | |
| Related Links | 20CTQ0, 20CTQ045STRL Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
