AVX Corporation 2225AC563KAT3A\SB
- Mfg. Part Number
- 2225AC563KAT3A\SB
- Manufacturer
- AVX Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 0.056UF 1KV X7R 2225
- Datasheet Download
- 2225AC563KAT3A\SB.pdf
Availability of 2225AC563KAT3A\SB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.01400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2225AC563KAT3A\SB, we specialize in AVX Corporation all series electronic components. 2225AC563KAT3A\SB can be shipped within 24 hours after order. If you have any demands for 2225AC563KAT3A\SB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2225AC563KAT3A\SB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2225AC563KAT3A\SB
| Internal Part Number | EIS-2225AC563KAT3A\SB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Component Solutions for Smart Meter Applications | |
| Standard Package | 4,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 0.056µF | |
| Tolerance | ±10% | |
| Voltage - Rated | 1000V (1kV) | |
| Temperature Coefficient | X7R | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 2225 (5763 Metric) | |
| Size / Dimension | 0.225" L x 0.250" W (5.72mm x 6.35mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.100" (2.54mm) | |
| Lead Spacing | - | |
| Features | High Voltage | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2225AC563KAT3A\SB | |
| Related Links | 2225AC56, 2225AC563KAT3A\SB Datasheet, AVX Corporation Distributor | |
