Bel Fuse Inc. 24-12
- Mfg. Part Number
- 24-12
- Manufacturer
- Bel Fuse Inc.
- Product Category
- Power Transformers
- Brief Description
- XFRMR LAMINATED 288VA CHAS MOUNT
- Datasheet Download
- 24-12.pdf
Availability of 24-12
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 108.41000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 24-12, we specialize in Bel Fuse Inc. all series electronic components. 24-12 can be shipped within 24 hours after order. If you have any demands for 24-12, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 24-12 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
24-12
| Internal Part Number | EIS-24-12 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Compliance | |
| Standard Package | 1 | |
| Category | Transformers | |
| Family | Power Transformers | |
| Series | - | |
| Type | Laminated Core | |
| Voltage - Primary | 105V, 115V, 125V, 230V | |
| Voltage - Secondary (Full Load) | Parallel 12V, Series 24V | |
| Current - Output (Max) | Parallel 24A, Series 12A | |
| Primary Winding(s) | Single, Multiple Taps | |
| Secondary Winding(s) | Dual | |
| Center Tap | Yes | |
| Power - Max | 288 VA | |
| Mounting Type | Chassis Mount | |
| Termination Style | Solder, Quick Connect | |
| Size / Dimension | 114.30mm L x 114.30mm W | |
| Height - Seated (Max) | 95.30mm | |
| Voltage - Isolation | 1500Vrms | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 24-12 | |
| Related Links | 24, 24-12 Datasheet, Bel Fuse Inc. Distributor | |
