CTS Electronic Components 262XR253B
- Mfg. Part Number
- 262XR253B
- Manufacturer
- CTS Electronic Components
- Product Category
- Trimmer Potentiometers
- Brief Description
- TRIMMER 25K OHM 0.15W TH
- Datasheet Download
- 262XR253B.pdf
Availability of 262XR253B
Available Quantity
6085 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.21060
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 262XR253B, we specialize in CTS Electronic Components all series electronic components. 262XR253B can be shipped within 24 hours after order. If you have any demands for 262XR253B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 262XR253B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
262XR253B
| Internal Part Number | EIS-262XR253B | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Drawings | X262 Series Footprint | |
| Standard Package | 1,500 | |
| Category | Potentiometers, Variable Resistors | |
| Family | Trimmer Potentiometers | |
| Series | 262 | |
| Packaging | Bulk | |
| Resistance (Ohms) | 25k | |
| Power (Watts) | 0.15W | |
| Tolerance | ±20% | |
| Temperature Coefficient | - | |
| Number of Turns | Single | |
| Adjustment Type | Side Adjustment | |
| Resistive Material | Carbon | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Size / Dimension | Rectangular - 0.370" x 0.394" Face x 0.469" H (9.40mm x 10.00mm x 11.90mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 262XR253B | |
| Related Links | 262X, 262XR253B Datasheet, CTS Electronic Components Distributor | |
262XR253B Details Description
