ON Semiconductor 2N5060G
- Mfg. Part Number
- 2N5060G
- Manufacturer
- ON Semiconductor
- Product Category
- SCRs - Single
- Brief Description
- THYRISTOR SCR 0.8A 30V TO92
- Datasheet Download
- 2N5060G.pdf
Availability of 2N5060G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2N5060G, we specialize in ON Semiconductor all series electronic components. 2N5060G can be shipped within 24 hours after order. If you have any demands for 2N5060G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2N5060G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2N5060G
| Internal Part Number | EIS-2N5060G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 08/Nov/2014 Multiple Devices Revision 26/Nov/2014 | |
| PCN Design/Specification | Cu wire conversion/New compound 26/Jul/2013 | |
| Standard Package | 5,000 | |
| Category | Discrete Semiconductor Products | |
| Family | SCRs - Single | |
| Series | - | |
| Packaging | Bulk | |
| Voltage - Off State | 30V | |
| Voltage - Gate Trigger (Vgt) (Max) | 800mV | |
| Current - Gate Trigger (Igt) (Max) | 200µA | |
| Voltage - On State (Vtm) (Max) | 1.7V | |
| Current - On State (It (AV)) (Max) | 510mA | |
| Current - On State (It (RMS)) (Max) | 800mA | |
| Current - Hold (Ih) (Max) | 5mA | |
| Current - Off State (Max) | 10µA | |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 10A @ 60Hz | |
| SCR Type | Sensitive Gate | |
| Operating Temperature | -40°C ~ 110°C | |
| Mounting Type | Through Hole | |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | |
| Supplier Device Package | TO-92-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2N5060G | |
| Related Links | 2N5, 2N5060G Datasheet, ON Semiconductor Distributor | |
