TE Connectivity AMP Connectors 3-147438-1
- Mfg. Part Number
- 3-147438-1
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Terminals - PC Pin, Single Post Connectors
- Brief Description
- CONN PC PIN SQUARE 0.045 GOLD
- Datasheet Download
- 3-147438-1.pdf
Availability of 3-147438-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 3-147438-1, we specialize in TE Connectivity AMP Connectors all series electronic components. 3-147438-1 can be shipped within 24 hours after order. If you have any demands for 3-147438-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 3-147438-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
3-147438-1
| Internal Part Number | EIS-3-147438-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - PC Pin, Single Post Connectors | |
| Series | AMPMODU | |
| Packaging | Reel | |
| Terminal Type | Single Post | |
| Terminal Style | Pin Retention | |
| Pin Size - Above Flange | 0.045" (1.14mm) Square | |
| Pin Size - Below Flange | 0.045" (1.14mm) Square | |
| Length Above Flange | - | |
| Length Below Flange | - | |
| Length - Overall | 0.700" (17.78mm) | |
| Flange Diameter | - | |
| Mounting Hole Diameter | 0.070" ~ 0.077" (1.78mm ~ 1.96mm) | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit | |
| Insulation | Non-Insulated | |
| Board Thickness | 0.100" (2.54mm) | |
| Contact Material | Brass | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Material - Insulation | - | |
| Insulation Color | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 3-147438-1 | |
| Related Links | 3-147, 3-147438-1 Datasheet, TE Connectivity AMP Connectors Distributor | |
3-147438-1 Details Description
