EDAC Inc. 357-022-541-104
- Mfg. Part Number
- 357-022-541-104
- Manufacturer
- EDAC Inc.
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CARDEDGE 22POS .156 BLACK LO PRO
- Datasheet Download
- 357-022-541-104.pdf
Availability of 357-022-541-104
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 23.23200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 357-022-541-104, we specialize in EDAC Inc. all series electronic components. 357-022-541-104 can be shipped within 24 hours after order. If you have any demands for 357-022-541-104, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 357-022-541-104 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
357-022-541-104
| Internal Part Number | EIS-357-022-541-104 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | 357 | |
| Packaging | Bulk | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 22 | |
| Number of Positions | 44 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.156" (3.96mm) | |
| Features | - | |
| Mounting Type | Through Hole | |
| Termination | Wire Wrap | |
| Contact Material | Copper, Nickel, Tin Alloy | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Contact Type | - | |
| Color | Black | |
| Flange Feature | Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia | |
| Operating Temperature | -65°C ~ 125°C | |
| Material - Insulation | Polyester Thermoplastic | |
| Read Out | Single | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 357-022-541-104 | |
| Related Links | 357-022, 357-022-541-104 Datasheet, EDAC Inc. Distributor | |
