Grayhill, Inc. 38DSP11B10M1GT
- Mfg. Part Number
- 38DSP11B10M1GT
- Manufacturer
- Grayhill, Inc.
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON SPDT 6A 125V
- Datasheet Download
- 38DSP11B10M1GT.pdf
Availability of 38DSP11B10M1GT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.24000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 38DSP11B10M1GT, we specialize in Grayhill, Inc. all series electronic components. 38DSP11B10M1GT can be shipped within 24 hours after order. If you have any demands for 38DSP11B10M1GT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 38DSP11B10M1GT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
38DSP11B10M1GT
| Internal Part Number | EIS-38DSP11B10M1GT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Compliance Status by Product Type | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | 38D | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | SPDT | |
| Switch Function | On-On | |
| Current Rating | 6A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Round, Plunger | |
| Color - Actuator/Cap | - | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Rear | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | - | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | - | |
| Electrical Life | 50,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 38DSP11B10M1GT | |
| Related Links | 38DSP11, 38DSP11B10M1GT Datasheet, Grayhill, Inc. Distributor | |
38DSP11B10M1GT Details Description
