TE Connectivity AMP Connectors 5-102618-4
- Mfg. Part Number
- 5-102618-4
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER VERT .100 12POS 15AU
- Datasheet Download
- 5-102618-4.pdf
Availability of 5-102618-4
Available Quantity
5736 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.35000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 5-102618-4, we specialize in TE Connectivity AMP Connectors all series electronic components. 5-102618-4 can be shipped within 24 hours after order. If you have any demands for 5-102618-4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 5-102618-4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
5-102618-4
| Internal Part Number | EIS-5-102618-4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 5-102618-4 Statement of ComplianceRoHS 2 Statement | |
| Featured Product | AMPMODU Connectors | |
| 3D Model | 5-102618-4.pdf | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 272 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | AMPMODU Mod II | |
| Packaging | Tray | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 12 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Contact Mating Length | 0.318" (8.08mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | Detent Lock | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 15µin (0.38µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 5-102618-4 | |
| Related Links | 5-102, 5-102618-4 Datasheet, TE Connectivity AMP Connectors Distributor | |
5-102618-4 Details Description
