TE Connectivity AMP Connectors 5-643818-1
- Mfg. Part Number
- 5-643818-1
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular Connectors - Free Hanging, Panel Mount
- Brief Description
- 21P MTA156 CONN ASSY 20AWG LF
- Datasheet Download
- 5-643818-1.pdf
Availability of 5-643818-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.75502
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 5-643818-1, we specialize in TE Connectivity AMP Connectors all series electronic components. 5-643818-1 can be shipped within 24 hours after order. If you have any demands for 5-643818-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 5-643818-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
5-643818-1
| Internal Part Number | EIS-5-643818-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 5-643818-1 Statement of ComplianceRoHS 2 Statement | |
| 3D Model | 5-643818-1.pdf | |
| PCN Design/Specification | Multiple Devices Housing color 25/Jul/2014 | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Free Hanging, Panel Mount | |
| Series | MTA-156 | |
| Packaging | Bulk | |
| Connector Type | Receptacle | |
| Contact Type | Female Socket | |
| Number of Positions | 21 | |
| Pitch | 0.156" (3.96mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Fastening Type | Locking Ramp | |
| Cable Termination | IDC | |
| Wire Type | Discrete or Ribbon Cable | |
| Wire Gauge | 20 AWG | |
| Features | Closed End, Polarizing Key | |
| Contact Finish | Tin | |
| Contact Finish Thickness | 80µin (2.03µm) | |
| Color | Yellow | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 5-643818-1 | |
| Related Links | 5-643, 5-643818-1 Datasheet, TE Connectivity AMP Connectors Distributor | |
5-643818-1 Details Description
