TE Connectivity AMP Connectors 5100161-4
- Mfg. Part Number
- 5100161-4
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Backplane Connectors - Hard Metric, Standard
- Brief Description
- CONN RCPT HM 55POS RT ANG 2MM
- Datasheet Download
- 5100161-4.pdf
Availability of 5100161-4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.72000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 5100161-4, we specialize in TE Connectivity AMP Connectors all series electronic components. 5100161-4 can be shipped within 24 hours after order. If you have any demands for 5100161-4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 5100161-4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
5100161-4
| Internal Part Number | EIS-5100161-4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 5100161-4 Statement of ComplianceRoHS 2 Statement | |
| 3D Model | 5100161-4.pdf | |
| Standard Package | 616 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Hard Metric, Standard | |
| Series | Z-PACK | |
| Packaging | Tube | |
| Connector Type | Receptacle, Female Sockets | |
| Connector Style | C 11 | |
| Number of Positions | 55 | |
| Number of Positions Loaded | All | |
| Pitch | 0.079" (2.00mm) | |
| Number of Rows | 5 | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Press-Fit | |
| Connector Usage | Backplane | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 1.5A | |
| Voltage Rating | 500V | |
| Operating Temperature | -55°C ~ 125°C | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 5100161-4 | |
| Related Links | 5100, 5100161-4 Datasheet, TE Connectivity AMP Connectors Distributor | |
5100161-4 Details Description
