Alpha Wire 5120/25C SL001
- Mfg. Part Number
- 5120/25C SL001
- Manufacturer
- Alpha Wire
- Product Category
- Multiple Conductor Cables
- Brief Description
- CABLE 25COND 24AWG SHLD 1000'
- Datasheet Download
- 5120/25C SL001.pdf
Availability of 5120/25C SL001
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 5120/25C SL001, we specialize in Alpha Wire all series electronic components. 5120/25C SL001 can be shipped within 24 hours after order. If you have any demands for 5120/25C SL001, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 5120/25C SL001 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
5120/25C SL001
| Internal Part Number | EIS-5120/25C SL001 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Basics of Wire and Cable | |
| Video File | How to Strip a Cable Using the Rip Cord | |
| Featured Product | Xtra-Guard® 1 Xtra-Guard® 2 Cable Line | |
| PCN Design/Specification | Xtra Guard 1 Cables 12/Aug/2015 | |
| Standard Package | 1 | |
| Category | Cables, Wires | |
| Family | Multiple Conductor Cables | |
| Series | Xtra-Guard® 1 | |
| Cable Type | Multi-Conductor | |
| Number of Conductors | 25 | |
| Wire Gauge | 24 AWG | |
| Conductor Strand | 7/32 | |
| Conductor Material | Copper, Tinned | |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) | |
| Jacket (Insulation) Diameter | 0.360" (9.14mm) | |
| Shield Type | Foil, Braid | |
| Length | 1000' (304.8m) | |
| Jacket Color | Slate | |
| Ratings | - | |
| Features | Drain Wire, Rip Cord | |
| Voltage | 300V | |
| Operating Temperature | -35°C ~ 105°C | |
| Usage | Communication, Control | |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) | |
| Jacket (Insulation) Thickness | 0.032" (0.81mm) | |
| Shield Material | Suprashield®; Copper, Tinned | |
| Shield Coverage | 100%, 70% | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 5120/25C SL001 | |
| Related Links | 5120/25, 5120/25C SL001 Datasheet, Alpha Wire Distributor | |
5120/25C SL001 Details Description
