Grayhill, Inc. 51SP22-01-1-08S
- Mfg. Part Number
- 51SP22-01-1-08S
- Manufacturer
- Grayhill, Inc.
- Product Category
- Rotary Switches
- Brief Description
- SWITCH ROTARY SP8T
- Datasheet Download
- 51SP22-01-1-08S.pdf
Availability of 51SP22-01-1-08S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 24.28440
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 51SP22-01-1-08S, we specialize in Grayhill, Inc. all series electronic components. 51SP22-01-1-08S can be shipped within 24 hours after order. If you have any demands for 51SP22-01-1-08S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 51SP22-01-1-08S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
51SP22-01-1-08S
| Internal Part Number | EIS-51SP22-01-1-08S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rotary Switches | |
| Series | 51 | |
| Number of Positions | 8 | |
| Index Stops | Fixed | |
| Number of Decks | 1 | |
| Number of Poles per Deck | 1 | |
| Circuit per Deck | SP8T | |
| Contact Timing | Shorting (MBB) | |
| Current Rating | 150mA (AC), 200mA (DC) | |
| Voltage Rating - AC | 115V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Flatted (3.17mm Dia) | |
| Actuator Length | 9.53mm | |
| Angle of Throw | 22.5° | |
| Contact Material | - | |
| Contact Finish | Gold | |
| Mounting Type | Panel Mount, Through Hole | |
| Termination Style | PC Pin | |
| Features | Shaft and Panel Sealed | |
| Depth Behind Panel | 13.64mm | |
| Panel Cutout Dimensions | Circular - 6.45mm Dia | |
| Operating Force, Torque | 8 ~ 24 in-oz | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 51SP22-01-1-08S | |
| Related Links | 51SP22-, 51SP22-01-1-08S Datasheet, Grayhill, Inc. Distributor | |
51SP22-01-1-08S Details Description
