Phoenix Contact 5452246
- Mfg. Part Number
- 5452246
- Manufacturer
- Phoenix Contact
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- BCP-508-15 BK
- Datasheet Download
- 5452246.pdf
Availability of 5452246
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.51000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 5452246, we specialize in Phoenix Contact all series electronic components. 5452246 can be shipped within 24 hours after order. If you have any demands for 5452246, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 5452246 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
5452246
| Internal Part Number | EIS-5452246 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | BCP | |
| Packaging | Bulk | |
| Type | Plug, Female Sockets | |
| Number of Positions | 15 | |
| Positions Per Level | 15 | |
| Number of Levels | 1 | |
| Pitch | 0.200" (5.08mm) | |
| Header Orientation | - | |
| Plug Wire Entry | 180° | |
| Termination Style | Screw | |
| Mounting Type | Free Hanging (In-Line) | |
| Current - IEC | 12A | |
| Voltage - IEC | 320V | |
| Current - UL | 15A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | 12-30 AWG | |
| Wire Gauge or Range - mm² | - | |
| Color | Black | |
| Operating Temperature | - | |
| Contact Mating Finish | Tin | |
| Features | Retention Latches (Non-Wire Side) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 5452246 | |
| Related Links | 545, 5452246 Datasheet, Phoenix Contact Distributor | |
5452246 Details Description
