C&K Components 7103J60AV2QE2
- Mfg. Part Number
- 7103J60AV2QE2
- Manufacturer
- C&K Components
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER SPDT 5A 120V
- Datasheet Download
- 7103J60AV2QE2.pdf
Availability of 7103J60AV2QE2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.77460
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7103J60AV2QE2, we specialize in C&K Components all series electronic components. 7103J60AV2QE2 can be shipped within 24 hours after order. If you have any demands for 7103J60AV2QE2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7103J60AV2QE2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7103J60AV2QE2
| Internal Part Number | EIS-7103J60AV2QE2 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Off-On | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Paddle | |
| Color - Actuator/Cap | Black | |
| Actuator Marking | No Marking | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole, Right Angle, Vertical | |
| Termination Style | PC Pin | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | - | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | - | |
| Electrical Life | 40,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7103J60AV2QE2 | |
| Related Links | 7103J6, 7103J60AV2QE2 Datasheet, C&K Components Distributor | |
