C&K Components 7103P3DZBES
- Mfg. Part Number
- 7103P3DZBES
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE SPDT 0.4VA 20V
- Datasheet Download
- 7103P3DZBES.pdf
Availability of 7103P3DZBES
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.59860
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7103P3DZBES, we specialize in C&K Components all series electronic components. 7103P3DZBES can be shipped within 24 hours after order. If you have any demands for 7103P3DZBES, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7103P3DZBES Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7103P3DZBES
| Internal Part Number | EIS-7103P3DZBES | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Off-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 20V | |
| Voltage Rating - DC | 20V | |
| Actuator Type | Flat Anti-Rotation | |
| Actuator Length | 13.21mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | - | |
| Features | Satin Chrome Actuator | |
| Actuator Material | Brass | |
| Electrical Life | 40,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7103P3DZBES | |
| Related Links | 7103P, 7103P3DZBES Datasheet, C&K Components Distributor | |
7103P3DZBES Details Description
