C&K Components 7108SYZQE22
- Mfg. Part Number
- 7108SYZQE22
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE SPDT 5A 120V
- Datasheet Download
- 7108SYZQE22.pdf
Availability of 7108SYZQE22
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.44220
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7108SYZQE22, we specialize in C&K Components all series electronic components. 7108SYZQE22 can be shipped within 24 hours after order. If you have any demands for 7108SYZQE22, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7108SYZQE22 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7108SYZQE22
| Internal Part Number | EIS-7108SYZQE22 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Standard Round | |
| Actuator Length | 10.67mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | - | |
| Features | Black Actuator | |
| Actuator Material | Brass | |
| Electrical Life | 40,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7108SYZQE22 | |
| Related Links | 7108S, 7108SYZQE22 Datasheet, C&K Components Distributor | |
7108SYZQE22 Details Description
